Used in a variety of applications: Some of the typical uses of grade 316 include chemical equipment, consumer and industrial products, exhausts, flanges and valves, hardware and fasteners, heat exchangers, HVAC, pipes and tubes, pharmaceutical equipment, photographic equipment, pulp paper and textile processing equipment and tanks. It is most often used where parts are exposed to severe environments.
Able to be processed in many ways: Metal processors and fabricators stamp, form, draw, bend, cut and weld alloy 316 to produce various parts. Cold working will increase strength and hardness.
GAUGE RANGE.004" to .190" (.102 mm to 4.826 mm)WIDTH RANGE.250" to 60" (6.365 mm to 1524 mm)ID8, 12, 16 or 20 (inches)OD78" maximumCOIL WEIGHT40,000 lbs maximum
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| Annealed | 75 | -515 | 30 | -205 | 40 | B-95 max. |
